PRODUCT NUMBER

MLY-D24M-A20PA-R1

CPU SOCKET

LGA2066, LGA2011-v3, LGA2011, LGA1151, LGA1150, LGA1155, LGA1156, LGA1366, LGA775, TR4, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1

WATERBLOCK DIMENSIONS

85 x 80 x 41.7 mm

RADIATOR DIMENSIONS

277 x 120 x 27 mm

RADIATOR MATERIAL

Aluminum

FAN DIMENSIONS (L X W X H)

120 x 120 x 26 mm / 4.7 x 4.7 x 1 inch

FAN SPEED

2000 ±10% RPM (Max)

FAN AIRFLOW

60.95 CFM (Max)

FAN AIR PRESSURE

2.33 mmH2O (Max)

FAN NOISE LEVEL

27 dBA (1m)

FAN POWER CONNECTOR

4-Pin (PWM), 3-Pin ARGB

FAN RATED VOLTAGE

12V DC

FAN RATED CURRENT

0.30A

FAN POWER CONSUMPTION

3.60W

FAN LED COLOR

ARGB

PUMP MTTF

160,000 Hours

PUMP NOISE LEVEL

< 20 dBA (1m)

PUMP RATED VOLTAGE

12 VDC

PUMP POWER CONSUMPTION

3.96W

CONNECTOR

4-Pin

EAN CODE

4719512078204

SERIES

MasterLiquid

COOLER TYPE

Liquid Cooler

RADIATOR SIZE

240

Document

• Product Sheet
• Manual

Software

• MasterPlus+ (Please manually update Firmware before installing MasterPlus)
• Firmware for Mirage: ARGB BOX V2
• CPU-Z - Cooler Master 32 & 64-bit versions
